Dimensions :

DIMENSIONS

TARE WEIGHT

9000KG

VOLUME

40m³

overall length

11980mm

overallwidth

2500mm

overall height

3800mm

specification

 tank body

q235/5mm steel

     end plate

q235a/6mm steel  sheet

     axle

number  3   brand  optional  capacity  13t

suspension

mechanical suspension or Air suspension

    leaf spring

leaf spring or Air  bag

    manhole cover

500mm manhole cover .2sets with 2breather valve

    tire

11.00r20，12.00r20，11r22.5，315/80r22.5 tire optional

    wheel rim

8.5-20,8.25-20,9.0-22.5,steel wheel rim optional upon choice

    discharge valve

2-4 set∮100mm discharge valves

    ischargepipe

4’'rubber hose，2pcs，6m long

    king pin

2''/3.5''bolt-in king pin

    landinggear

jostbrandtwo-speed， manualoperating，heavy duty landing gear

    bottom valve

1-2 sets of bottom valve

    qutside sheet

1.52mm steel sheet

    compartment

optional upon choice

    braking system

wabco re6 reay valve：t30/30spring brake chamber：40l air tanks

    painting

complete chassis sand blasting to clean rust，1cpat of anticorrosive prime， 2coats of final

    accessories

one standard tool box

    main beams

opting for high tensile steel q345b welded by automatic submerged-arc process
