DIMENSIONS |
|||||||
Tare weight |
10000kg |
Payload |
50000kg |
||||
Overall Length |
12000mm |
Overall Width |
2500mm |
Overall height |
4000mm |
Specification :
SPECIFICATION |
|||||
Chassis |
Heavy duty and extra durability designed i beam;opting
for high tensile steel Q345,welded
by automatic subrnerged-Arc processes. Top plate 16mm.width 200mm.Middle
Flange 8mm;bottom flange 18mm.width 200mm |
||||
Axle |
Number |
3 |
Brand |
Optional upon choice |
Capacity |
Suspension |
Mechanical suspension Or air suspension |
||||
Leaf spring |
Leaf spring or air bag |
||||
Floor |
checkered plate |
||||
Tire |
11.00R20,12.00R20,11R22.5,12R22.5,315/80R22.5
Tire optional |
||||
Wheel rim |
8.5-20,9.0-20,8.25-22.5,9.0-22.5 steel
wheel rim optional upon choice |
||||
Kingpin |
2”/3.5”bolt-in king pin |
||||
Landing gear |
JOST brand two-speed,manual operation,heavy
duty landing gear |
||||
Vehicular applications |
Cargo transport |
||||
Braking system |
RE6 relay valve;T30/30 sping brake chamber;40L
air tanks |
||||
Painting |
Complete chassis sand blasting to clean rust,1coat
of anticorrosive prime,2coats of final paint |
||||
Accessories |
One standard tool box |
If you have any question or demand of trucks ,pls kindly contact us.
