Dimensions :

DIMENSIONS

Tare  weight

   6000kg

     Payload

40000 kg

Overall  length

                             12470mm

                  Overall  Width

   2500mm

                    Overall height

           1550mm

SPECIFICATION

Chassis

Heavy duty and extra durability designed i beam；opting for high  tensile steel Q345，welded by automatic subrnerged-Arc processes. Top flange 14mm，Middle Flange 8mm；bottom flange16mm，width 140mm

Axle

Number

3

Brand

Optional upon choice

Capacity

Suspension

Mechanical suspension Or air suspension

Leaf spring

Leaf spring or air bag

Tire

11.00R20，12.00R20，11R22.5，12R22.5，315/80R22.5 Tire optional

Wheel rim

rim 8.5-20，9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice

Kingpin

2”/3.5”bolt-in king pin

Landing gear

JOST brand two-speed，manual operation，heavy duty landing gear

Twist lock

12no.of ISO twist lock for 1×20ft，2×20ft，1×40ft container

Vehicular applications

Container（20ft.40ft.45ft）transport

Braking system

WABCO RE6 relay valve；T30/30 sping brake chamber；40L air tanks

Painting

Complete chassis sand blasting to clean rust，1coat of anticorrosive prime，2coats of final paint

Accessories

one standard tool box
