NO. | Part No. | Part Name | Quantity |
1 | 2159328001 | Gear shift fork | 1 |
3 | 1295334027 | Sliding pad | 2 |
6 | 631329086 | Slotted spring pin | 1 |
7 | 730260355 | Bush | 2 |
8 | 630361078 | Sealing cap | 1 |
9 | 630603010 | Locking plate | 1 |
11 | 1269288045 | Detent plunger | 1 |
11/A | 1269228045 | Detent plunger | 1 |
16 | 1269334002 | Gear shift shaft | 1 |
20 | 634300855 | Shaft seal | 1 |
21 | 634307405 | Rod wiper | 1 |
24 | 1269328252 | gear shift lever | 1 |
25 | 636010092 | Hexagon screw | 1 |
27 | 637006018 | Hexagon nut | 1 |
33 | 750132019 | cylinder | 1 |
35 | 634308009 | Silent block | 1 |
37 | 501305189 | Fork head | 1 |
41 | 501298046 | Repair set | 1 |
41/A | 501289046 | Repair set | 1 |
43 | 734320116 | Bellows | 1 |
44 | 501304049 | Screen | 1 |
47 | 631202086 | Bolt | 2 |
48 | 630001065 | Washer | 1 |
49 | Q43114 | Retaining ring | 1 |
50 | 1229201016 | Cylinder suspension | 1 |
52 | 636015278 | Screw | 4 |
52/A | 6360150278 | Screw | 4 |
53 | 630001052 | Washer | 1 |
54 | 631701145 | Split pin | 1 |
