| NO. | Part No. | Part Name | Quantity |
| - | VG1560080278A | Injection pipe set | 1 |
| 1 | VG1560080278A-1 | Injection pipe for 1st cylinder | 1 |
| 2 | VG1560080278A-2 | Injection pipe for 2nd cylinder | 1 |
| 3 | VG1560080278A-3 | Injection pipe for 3rd cylinder | 1 |
| 4 | VG1560080278A-4 | Injection pipe for 4th cylinder | 1 |
| 5 | VG1560080278A-5 | Injection pipe for 5th cylinder | 1 |
| 6 | VG1560080278A-6 | Injection pipe for 6th cylinder | 1 |
| 7 | VG1560080302 | Injection pump/CB6P821 | 1 |
| 7/A | VG1560080023 | Injection pump | 1 |
| 7/1 | VG1500080100 | Fuel pump | 1 |
| 8 | VG1560080276 | Nozzle holder/P036 | 6 |
| 9 | VG1560080277 | Coupler | 1 |
| 9/A | VG1560080300 | Coupler | 1 |
| 10 | VG1560080261 | Flange | 1 |
| 11 | VG14080074 | Bracket | 1 |
| 11/A | VG1500080174 | Bracket | 1 |
| 12 | VG1500080090 | Hollow screw | 6 |
| 13 | VG1500080094A | Pressure clip | 6 |
| 14 | VG1560070025 | Lubricating oil reversal | 1 |
| 19 | VG2600080200 | Gasket | 4 |
| 20 | 190003930271 | Washer | 4 |
| 21 | 190003862566 | Screw | 4 |
| 22 | VG2600080383 | Screw | 12 |
| 23 | 190003901600 | Dowel | 2 |
| 24 | 190003802321 | Screw | 4 |
| 25 | 190003871232 | Nut | 6 |
| 26 | VG9003080001 | Gasket | 12 |
| 28 | 190003802312 | Screw | 2 |
| 29 | VG14080082 | Gasket | 6 |
| 30 | 190003802650 | Screw | 4 |
| 31 | VG609070080 | Gasket | 6 |
| 32 | VG1560080172 | Support plate | 4 |
