| NO. | Part No. | Part Name | Quantity |
| 1 | WG1642820002 | Air conditioner with electro air intake | 1 |
| 1/1 | AZ1630840013 | Bottom housing | 1 |
| 1/2 | AZ1630840091 | Water pipe | 2 |
| 1/3 | AZ1630840319 | Water tank with electro valve | 1 |
| 01/3/1 | AZ1630840074 | Water tank | 1 |
| 01/3/2 | AZ1630840073 | Water inlet pipe assembly | 1 |
| 01/3/3 | AZ1630840066 | O-ring | 3 |
| 01/3/4 | AZ1630840072 | Water outlet pipe assembly | 1 |
| 01/3/5 | AZ1630840320 | Water valve with electro switch | 1 |
| 1/4 | AZ1630840326 | 3# water changer | 1 |
| 1/5 | Q2723525 | Screw | 2 |
| 1/6 | AZ1642820010 | Evaporator assembly | 1 |
| 01/6/1 | AZ1642820010-1 | Expansion valve | 1 |
| 01/6/2 | AZ1642820010-2 | Temperature sensor | 1 |
| 1/7 | AZ1630840015 | Air intake assembly | 2 |
| 1/8 | AZ1630840312 | Middle housing | 1 |
| 1/9 | AZ1630840092 | Seal strip | 1 |
| 1/10 | AZ1630840063 | Clip | 9 |
| 1/11 | AZ1630840014 | Fan | 1 |
| 1/12 | AZ1630840323 | Electrical line for fan | 1 |
| 1/13 | Q2714216 | Screw | 3 |
| 1/14 | AZ1630840321 | Fan speed changer | 1 |
| 1/15 | AZ1630840049 | Rotary plate | 1 |
| 1/16 | AZ1630840050 | Rotary arm | 1 |
| 1/17 | AZ1630840051 | Torsion spring | 21 |
| 1/18 | AZ1630840052 | Washer | 1 |
| 1/19 | AZ1630840065 | Snap ring | 1 |
| 1/20 | AZ1630840045 | Rod II | 2 |
| 1/21 | AZ1630840046 | Rod III | 1 |
| 1/23 | AZ1630840325 | 2# water changer | 1 |
| 1/24 | Q2723525 | Screw | 2 |
| 1/25 | AZ1630840313 | Lever | 1 |
| 1/26 | AZ1630840314 | Rod | 1 |
| 1/27 | AZ1630840053 | Base | 2 |
| 1/28 | AZ1630840311 | Above housing | 1 |
| 1/29 | AZ1630840401 | Gasket | 1 |
| 1/30 | AZ1630840093 | Seal strip II | 1 |
| 1/31 | AZ1630840063 | Clip | 8 |
| 1-32 | AZ1630840037 | Air intake left | 1 |
| 1-33 | AZ1630840038 | Air intake right | 1 |
| 1-34 | AZ1630840040 | Air intake front | 1 |
| 1-35 | AZ1630840041 | Rod | 2 |
| 1-36 | AZ1630840035 | Shaft | 1 |
| 1-37 | AZ1630840036 | Air intake rear | 1 |
| 1-38 | AZ1630840039 | Rod I | 1 |
| 1-39 | AZ1630840053 | Base | 1 |
| 1-40 | AZ1630840034 | Bevel gear | 2 |
| 1-41 | AZ1630840315 | Shaft for bevel gear | 1 |
| 1-42 | Q43660 | Snap ring | 1 |
| 1-43 | AZ1630840324 | 1# water changer | 1 |
| 1-44 | Q2723525 | Screw | 2 |
| 1-45 | AZ1630840016 | Seal ring | 1 |
| 1-46 | AZ1630840021 | Plate | 1 |
