DRIVER'S CAB
UPPER SHELL ASSEMBLY

2015-04-16 14:18:11



NO PART NO QUANTITY Designation
63 AZ1664820034 1 Upper shell 空调上壳体
64 AZ1664820046 1 Bearing 水阀摆杆
65 WG1664820054/1 1 Driver / branch flow control 旁通风门控制电机
66 Q2713525 3 Selftaping screw 十字槽盘头自攻螺钉
67 AZ1664820049 1 Stick 旁通风门摆杆
68 AZ1664820051 1 Stick 旁通风门连杆
69 AZ1630840053 2 Joint 莲花座
70 AZ1664820064 1 Holder 散热芯左压紧垫块
71 Q2744295 2 Counter sunk screw 十字槽沉头自攻螺钉
72 AZ1664820050 1 Shutter / branch flow 旁通风门
73 AZ1664820066 1 Holder 散热芯右压紧垫块(与左件对称)
74 Q2744295 2 Counter sunk screw 十字槽沉头自攻螺钉
75 AZ1664820047 1 Bearing 水阀同步摆杆
76 AZ1664820048 1 Axis 方轴
77 WG1664820045/1 1 Driver / shutter control 模式风门控制电机
78 Q2713525 3 Selftaping screw 十字槽盘头自攻螺钉
79 AZ1664820035 1 Stick 模式风门摆杆
80 AZ1664820044 1 Gear 模式风门短连杆
81 AZ1664820039 1 Gear 吹脸风门直连齿轮
82 AZ1664820038 1 Gear 除霜风门直连齿轮
83 AZ1664820037 1 Gear 吹脚风门直连齿轮
84 AZ1664820036 1 Gear 模式风门过渡齿轮
85 AZ1664820043 1 Stick 模式风门长连杆
86 AZ1664820040 2 Shutter / defrost & foot 模式风门总成
87 AZ1664820069 1 Shutter / face 吹脸风门
