| NO. | Part No. | Chinese Name | Part Name |
| 1 | 90003802578 | 六角头螺栓 | Bolt |
| 2 | 90003931122 | 弹簧垫圈 | Spring washer |
| 3 | 900033114lO | 向心球轴承 | Bearing |
| 4 | 90003934732 | 带凸齿的孔用挡圈 | Snap ring |
| 5 | 6140749 | 中间隔圈 | Ring |
| 6 | 61407006l | 机油泵中间齿轮 | Gear |
| 7 | 614070155 | 密封圈 | Seal ring |
| 8 | 6140756 | 中间齿轮轴 | Gear shaft |
| 9 | 90003800551 | 六角头螺栓 | Bolt |
| 10 | AZl500070021A | 48mm 加宽机油泵 | Oil pump |
| 10月1日 | 61500070029 | 机油泵前盖 | Front cover |
| 42279 | AZ1500070019A | 机油泵齿轮总成 | Gear assy |
| 42280 | AZ1500070015A | 机油泵壳体 | Housing |
| 42281 | 90003901420 | 圆柱销 | Pin |
| 42282 | 61500070024 | 机油泵后盖 | Rear cover |
| 42283 | 内六角圆柱头螺钉 | Screw | |
| 42284 | 614070060 | 机油泵驱动齿轮 | Gear |
| 42285 | 90003802569 | 六角头螺栓 | Bolt |
| 42286 | AZ1500070020A | 机油泵齿轮总成 | Gear |
| 42287 | 90012210003 | 1 型六角螺母 | Nut |
| 42288 | 90003800458 | 六角头螺栓 | Bolt |
| 42289 | 90003800441 | 六角头螺栓 | Bolt |
| 11 | 614070055 | 机油泵垫片 | Shim |
| 12 | 614070078 | 垫片 | Shim |
| 13 | 90003930271 | 平垫圈 | Washer |
| 14 | 90003802523 | 六角头螺栓 | Bolt |
| 15 | 61800070051 | 集滤器总成 | Filter |
| 16 | 90003802527 | 六角头螺栓 | Bolt |
| 17 | 61500070099 | 机油泵限压阀总成 | Release valve C |
| 42021 | 61500070098 | 限压阀体 | Valve body |
| 42052 | AZ9003930011 | 孔用弹性挡圈 | Snap ring |
| 42080 | 614070130 | 限压阀 | Valve |
| 42111 | 614070131 | 弹簧 | Spring |
| 42141 | 681270027 | 垫片 | Shim |
