LUBRICATING OIL PUMP AND OIL FILTER

Product catalog

D12 EURO 2

LUBRICATING OIL PUMP AND OIL FILTER

2016-09-27 12:07:50

1	VG1246110002	进气管	Intake manifold
2	190003989286	碗形塞	Core hole plug
3	VG1246110006	进气管垫片	Gasket
4	Q150B08125	六角头螺栓	Hex head bolt
5	Q150B08115	六角头螺栓	Hex head bolt
6	Q150B08110	六角头螺栓	Hex head bolt
7	Q41808	波形弹簧垫圈	Spring washer
8	VG1246110044	共轨支架总成	Bracket
9	VG1540110011A	进气管盖板	Intake manifold cover
10	VG1540110018A	进气管盖板垫片	Gasket
11	Q150B0620	六角头螺栓	Hex head bolt
12	Q41806	波形垫片	Spring washer
13	VG1246110100	进气接管	Intake pipe connector
	VG1246110093	进气接管	Intake pipe connector
14	VG1560110180	进气接管垫片	Gasket
15	Q1201030F3	双头螺柱	Stud
16	Q41810	波形弹性垫圈	Spring washer
17	Q340B10	六角螺母	Hexagon nut
18	VG1540110038	管接头	Pipe tie-in
19	VG1540110037	空心螺栓	Hollow bolt
20	VG9003080003	复合密封垫圈	Sealing washer
21	VG1246110106	橡胶软管	Hose
22	190003989300	软管卡箍	Pipe clip
23	VG1246110021	增压器	Turbocharger
24	VG1540110017	增压器垫片	Gasket
25	VG1500110002	耐热螺栓	Bolt
26	VG1246110058	增压器螺栓	Bolt
27	VG1246110108	前排气岐管	Front exhaust manifold
28	VG1246110109	中排气岐管	Mid exhaust manifold
29	VG1246110110	后排气歧管	Rear exhaust manifold
30	VG1246110027	排气管密封环	Laminated sealing ring
31	VG1246110028	排气管垫片	Gasket
32	VG1246110052	排气管紧固螺栓	Bolt
33	VG1246110111	后排气管隔热罩	Rear heat insulation cover
34	VG1246110112	前排气管隔热罩	Front heat insulation cover
35	VG1500110963	耐热螺栓	Bolt
36	Q40208	大垫圈	Washer
37	VG1246110113	耐热螺栓	Bolt
38	Q40308	弹簧垫圈	Spring washer
39	Q40108	平垫圈	Washer
40	VG1246110053	增压器进油管总成	Oil supply pipe assembly
41	VG1246110046	进油管座	Two bolt flange
42	VG9003080007	复合密封垫圈	Sealing washer
43	VG1560110152	进油管法兰	Flange
44	VG609E110050	进油管垫片	Gasket
45	Q218B0825	内六角圆柱头螺钉
