Home WP10 THREE SERIES
WP10 THREE SERIES
FUEL INJECTION SYSTEM

2015-11-24 22:00:15



 NO. Part No. Chinese Name Part Name
1 612600080616 回油管总成 Oil line
2 90003962603 空心螺栓 Bolt
3 612600080201 密封垫圈 Seal washer
4 612600080652 回油管 Oil line
5 612600080653 回油管 Oil line
6 61260008065 三通管接头 Pipe connector
7 612639000049 空心螺栓 Bolt
8 612639000048 密封垫圈 Seal washer
9 612639000017 空心螺栓 Bolt
10 612639000018 密封垫圈 Seal washer
11 612639000049 空心螺栓 Bolt
12 612639000048 密封垫圈 Seal washer
13 612600080621 燃油管总成 Fuel oil pipe
14 612600080622 燃油管总成 Fuel oil pipe
15 612600080623 燃油管总成 Fuel oil pipe
16 612600080624 燃油管总成 Fuel oil pipe
17 612639000090 六角头螺栓 Hexagon bolt
18 90003802532 六角头螺栓 Hexagon bolt
19 90003802523 六角头螺栓 Hexagon bolt
20 90003802523 六角头螺栓 Hexagon bolt
21 90003802532 六角头螺栓 Hexagon bolt
22 612639000090 六角头螺栓 Hexagon bolt
23 612600080671 精滤固定板 Bracket
24 612600070185 润滑油进油管组件 Oil line
25 612630030055 空心螺栓 Bolt
26 612639000050 六角头螺栓 Hexagon bolt
27 612630080110 电控单元组件 ECU
28 612630080012 粗滤器 Pre_filter
29 612630080011 精滤器 Main_filter
