| NO. | Part No. | Chinese Name | Part Name |
| 1 | 612600010932 | 正时齿轮室 | Timing gear case |
| 2 | 61500010175 | 空压机齿轮盖 | Gear cover |
| 3 | 614010040 | 空齿轮盖垫片 | Gasket |
| 4 | 614010070 | 凸轮轴齿轮盖垫片 | Gasket |
| 5 | 612600010122 | 飞轮壳 | Flywheel housing |
| 6 | 61500010101 | 飞轮壳螺栓 | Flywheel housing bolt |
| 7 | 61500010062 | 飞轮壳螺栓 | Flywheel housing bolt |
| 8 | 61500010037 | 前油封 | Front oil seal |
| 9 | 612600010928 | 前油封座 | Oil seal support |
| 10 | 6126000114435 | 六角头螺栓 | Bolt |
| 11 | 612600011654 | 机油冷却器盖总成 | Cover，oil cooler |
| 12 | 612600010062 | 观察孔盖 | Cover，sight window |
| 13 | 614010084B | 机油冷却器盖垫片 | Gasket，oil cooler |
| 14 | 100GF.06 | 前支架(右) | Bracket |
| 15 | 100CF.07 | 前支架(左) | Bracket |
| 16 | 100GF.08 | 后支架(左) | Bracket |
| 17 | 100GF.09 | 后支架(右) | Bracket |
| 18 | 90003802511 | 六角头螺栓 | Hexagon bolt |
| 19 | 90003802523 | 六角头螺栓 | Hexagon bolt |
| 20 | 90003802561 | 六角头螺栓 | Hexagon bolt |
| 21 | 90003802576 | 六角头螺栓 | Hexagon bolt |
| 22 | 612600010760 | 铭牌 | Nameplate |
| 23 | 612600011335 | 中国名牌用铭牌 | Nameplate |
| 24 | 90003800458 | 六角头螺栓 | Hexagon bolt |
| 25 | 90003800571 | 六角头螺栓 | Hexagon bolt |
| 26 | 90003802424 | 六角头螺栓 | Hexagon bolt |
| 27 | 612600010791 | 标牌铆钉 | Bolt |
| 28 | 90003813429 | 双头螺柱 | Stud |
| 29 | 90003813470 | 双头螺柱 | Stud |
| 30 | 90003811531 | 双头螺柱 | Stud |
| 31 | 90003813648 | 双头螺柱 | Stud |
| 32 | 90003932023 | 波形弹性垫圈 | Spring washer |
| 33 | 90003813527 | 双头螺柱 | Stud |
| 34 | 90003802527 | 六角头螺栓 | Hexagon bolt |
| 35 | 90003888452 | 2型全金属六角锁紧螺母 | Hexagon nut(Ⅱ) |
| 36 | 90003888453 | 2型全金属六角锁紧螺母 | Hexagon nut(Ⅱ) |
| 37 | 90003871252 | 1型六角螺母 | Hexagon nut(Ⅰ) |
| 38 | 90003962621 | 空心螺栓 | Hollow screw |
| 39 | 90003098014 | 密封垫圈 | Seal ring |
| 40 | 90003098015 | 密封垫圈 | Seal ring |
| 41 | 90003931122 | 弹簧垫圈 | Spring washer |
| 42 | 90003932024 | 弹簧垫圈 | Spring washer |
| 43 | 90003930012 | 垫圈 | Washer |
| 44 | 90003930271 | 平垫圈 | Flat washer |
| 44 | 90003932025 | 鞍形弹性垫圈 | Spring washer |
| 45 | 90003909603 | 弹性圆柱销 | Dowel pin |
| 46 | 90003901507 | 圆柱销 | Dowel pin |
| 47 | 90003901604 | 圆柱销 | Dowel pin |
| 48 | 61560010047 | 喷嘴组件 | Nozzle |
| 49 | 612600010171 | 凸轮轴齿轮盖总成 | Cam shaft gear cover |
| 50 | 9000396205 1 | 六角头螺塞 | Screw plug |
| 51 | 612600010465 | 放水阀总成 | Valve |
| 52 | 612600010062 | 观察孔盖 | Cover,sight window |
