226B SERIES CONSTRUCTION MACHINERY
CRANKCASE ASSEMBLY(2)

2015-11-17 23:57:02



 NO. Part No. Chinese Name Part Name
17 12160117 焊接弯管 MANIFOLD
18 12160129 固定板 RETAINING PLATE
19 1177981 弹簧垫圈 SPRING LOCK WASHER
20 1151498 内六角圆柱头螺钉 CHEESE HEAD SCREW
21 1153869 0型密封圈 O-SEAL
23 1152717 碗形塞 COVER
24 13024173 气缸套 CYLINDER LINER
25 1153805 O型密封圈 O-SEAL
26 1153804 O型密封圈 O-SEAL
29 1113477 双头螺柱 STUD
13023472 双头螺柱 STUD
30 13021999 六角螺母 HEXAGON BOLT
31 12166173 平垫圈 PLAIN WASHER
1152752 平垫圈 PLAIN WASHER
32 1117867 齿形垫圈 TOOTH LOCK WASHER
33 12200620 气缸盖螺栓 CYLINDER HEAD BOLT
34 12200621 气缸盖螺栓 CYLINDER HEAD BOLT
35 12165568 平垫圈/垫片 PLAIN WASHER
36 1115413 弹性圆柱销 STRAIGHT PIN
37 1105156 圆柱销 PARALLEL PIN
38 1105182 圆柱销 PARALLEL PIN
39 13023589 气缸盖螺栓 CYLINDER HEAD BOLT
40 12164651 六角头螺栓 HEXAGON BOLT
44 13031278 套管 SLEEVE
12159445 套管 SLEEVE
45 13030191 停油拉线支架 BRACKET
13026681 停油拉线支架 BRACKET
13024818 停油拉线支架 BRACKET
13030203 停油拉线支架 BRACKET
13022903 停油拉线支架 BRACKET
46 1151599 双头螺柱 STUD
47 12167427 垫片 GASKET
48 1152783 六角螺母 HEXAGON BOLT
49 1151453 六角头螺塞 SCREW PLUG
