2015-11-18 18:10:04
| NO. | Part No. | Chinese Name | Part Name |
| 17 | 12160117 | 焊接弯管 | MANIFOLD |
| 18 | 12160129 | 固定板 | RETAINING PLATE |
| 19 | 1177981 | 弹簧垫圈 | SPRING LOCK WASHER |
| 20 | 1151498 | 内六角圆柱头螺钉 | CHEESE HEAD SCREW |
| 21 | 1153869 | 0型密封圈 | O-SEAL |
| 23 | 1152717 | 碗形塞 | COVER |
| 24 | 13024173 | 气缸套 | CYLINDER LINER |
| 25 | 1153805 | O型密封圈 | O-SEAL |
| 26 | 1153804 | O型密封圈 | O-SEAL |
| 29 | 1113477 | 双头螺柱 | STUD |
| 13023472 | 双头螺柱 | STUD | |
| 30 | 13021999 | 六角螺母 | HEXAGON BOLT |
| 31 | 12166173 | 平垫圈 | PLAIN WASHER |
| 1152752 | 平垫圈 | PLAIN WASHER | |
| 32 | 1117867 | 齿形垫圈 | TOOTH LOCK WASHER |
| 33 | 12200620 | 气缸盖螺栓 | CYLINDER HEAD BOLT |
| 34 | 12200621 | 气缸盖螺栓 | CYLINDER HEAD BOLT |
| 35 | 12165568 | 平垫圈/垫片 | PLAIN WASHER |
| 36 | 1115413 | 弹性圆柱销 | STRAIGHT PIN |
| 37 | 1105156 | 圆柱销 | PARALLEL PIN |
| 38 | 1105182 | 圆柱销 | PARALLEL PIN |
| 39 | 13023589 | 气缸盖螺栓 | CYLINDER HEAD BOLT |
| 40 | 12164651 | 六角头螺栓 | HEXAGON BOLT |
| 44 | 13031278 | 套管 | SLEEVE |
| 12159445 | 套管 | SLEEVE | |
| 45 | 13030191 | 停油拉线支架 | BRACKET |
| 13026681 | 停油拉线支架 | BRACKET | |
| 13024818 | 停油拉线支架 | BRACKET | |
| 13030203 | 停油拉线支架 | BRACKET | |
| 13022903 | 停油拉线支架 | BRACKET | |
| 46 | 1151599 | 双头螺柱 | STUD |
| 47 | 12167427 | 垫片 | GASKET |
| 48 | 1152783 | 六角螺母 | HEXAGON BOLT |
| 49 | 1151453 | 六角头螺塞 | SCREW PLUG |
